Orchestrator PostgreSQL Failover Configuration (Part 3)

ProxySQL handles traffic routing and detects role changes automatically (as we saw in Part 2), but it doesn't make promotion decisions. When the primary fails, something needs to promote a replica and rewire the remaining replicas to follow the new primary.

That's Orchestrator's job. The ProxySQL team forked Orchestrator and added PostgreSQL streaming replication support — topology discovery via pg_stat_replication, failure detection, and automated promotion via pg_promote(). Version 4.30+ supports PostgreSQL 15, 16, and 17.

What Orchestrator Does for PostgreSQL

Step 1: Install Orchestrator 4.30

Download and install the Orchestrator deb package on the proxy-orch VM:

# For ARM64 (Apple Silicon):
multipass exec proxy-orch -- sudo bash -c '
  wget -q https://github.com/ProxySQL/orchestrator/releases/download/v4.30.2/orchestrator_4.30.2_arm64.deb \
    -O /tmp/orchestrator.deb
  dpkg -i /tmp/orchestrator.deb
'

# For x86_64, replace arm64 with amd64 in the URL

The binary installs to /usr/local/orchestrator/orchestrator.

Also install orchestrator-client — a lightweight bash CLI that wraps the HTTP API. It gives you clean, scriptable access to topology and failover commands without writing curl | python3 pipelines:

# For ARM64 (Apple Silicon):
multipass exec proxy-orch -- sudo bash -c '
  wget -q https://github.com/ProxySQL/orchestrator/releases/download/v4.30.2/orchestrator-client_4.30.2_arm64.deb \
    -O /tmp/orch-client.deb
  dpkg -i /tmp/orch-client.deb
'

# For x86_64, replace arm64 with amd64

Set the API endpoint (add this to .bashrc for persistence):

multipass exec proxy-orch -- bash -c '
  echo "export ORCHESTRATOR_API=http://localhost:3098/api" >> ~/.bashrc
  export ORCHESTRATOR_API="http://localhost:3098/api"
  orchestrator-client -c help | head -5
'

Step 2: Create the PostgreSQL Configuration

Orchestrator's PostgreSQL support is activated by setting ProviderType to postgresql. The config file has four sections:

1. Connection — how Orchestrator connects to PostgreSQL backends
2. Polling — how often it checks each instance
3. Recovery — what to do when a primary dies (auto-promote or not)
4. Hooks — shell commands to run at each failover stage

Create the configuration file:

multipass exec proxy-orch -- sudo bash -c 'cat > /usr/local/orchestrator/orchestrator.conf.json << EOFCONFIG
{
  "Debug": true,
  "EnableSyslog": false,
  "ListenAddress": ":3098",

  "ProviderType": "postgresql",
  "PostgreSQLTopologyUser": "orchestrator",
  "PostgreSQLTopologyPassword": "orch_pass_2026",
  "PostgreSQLSSLMode": "disable",

  "DefaultInstancePort": 5432,
  "BackendDB": "sqlite",
  "SQLite3DataFile": "/usr/local/orchestrator/orchestrator.sqlite3",
  "InstancePollSeconds": 3,

  "UnseenInstanceForgetHours": 240,
  "SnapshotTopologiesIntervalHours": 0,
  "HostnameResolveMethod": "default",

  "ReasonableReplicationLagSeconds": 10,
  "ReasonableMaintenanceReplicationLagSeconds": 20,

  "FailureDetectionPeriodBlockMinutes": 1,
  "RecoveryPeriodBlockSeconds": 60,
  "RecoverMasterClusterFilters": ["_do_not_match_"],
  "RecoverIntermediateMasterClusterFilters": ["_do_not_match_"],

  "OnFailureDetectionProcesses": [
    "echo \"Detected {failureType} on {failureCluster}. Affected replicas: {countSlaves}\" >> /tmp/orchestrator-recovery.log"
  ],
  "PreFailoverProcesses": [
    "echo \"Will recover from {failureType} on {failureCluster}\" >> /tmp/orchestrator-recovery.log"
  ],
  "PostFailoverProcesses": [
    "echo \"Recovered from {failureType} on {failureCluster}. Failed: {failedHost}:{failedPort}; Successor: {successorHost}:{successorPort}\" >> /tmp/orchestrator-recovery.log"
  ],
  "PostMasterFailoverProcesses": [
    "echo \"Master failover complete. Failed: {failedHost}:{failedPort}; Promoted: {successorHost}:{successorPort}\" >> /tmp/orchestrator-recovery.log"
  ],

  "StatusEndpoint": "/api/status",
  "StatusSimpleHealth": true,
  "HTTPAuthUser": "",
  "HTTPAuthPassword": "",
  "PowerAuthUsers": ["*"],
  "ReadOnly": false
}
EOFCONFIG'

Key configuration explained:

Step 3: Start Orchestrator

multipass exec proxy-orch -- sudo bash -c '
  nohup /usr/local/orchestrator/orchestrator \
    -config /usr/local/orchestrator/orchestrator.conf.json \
    http > /tmp/orchestrator.log 2>&1 &

  sleep 3
  pgrep -f orchestrator && echo "Orchestrator running" || echo "FAILED"
'

Check the startup log:

multipass exec proxy-orch -- tail -5 /tmp/orchestrator.log

Expected output:

INFO continuous discovery: using PostgreSQL provider
INFO continuous discovery: starting

Step 4: Discover the Topology

Seed Orchestrator with the primary instance. It will automatically discover replicas by querying pg_stat_replication:

multipass exec proxy-orch -- curl -s http://localhost:3098/api/discover/pg-primary/5432

Expected response (truncated):

{
  "Code": "OK",
  "Message": "Instance discovered: pg-primary:5432",
  "Details": {
    "Key": {"Hostname": "pg-primary", "Port": 5432},
    "Version": "17.9",
    "ReadOnly": false,
    "Replicas": [
      {"Hostname": "192.168.2.7", "Port": 5432},
      {"Hostname": "192.168.2.8", "Port": 5432}
    ],
    "ProviderType": "postgresql"
  }
}

Orchestrator found the primary running PostgreSQL 17.9 and both replicas. Within a few seconds, it polls the replicas too and builds the full topology tree.

Step 5: Verify the Topology

Check the cluster information:

multipass exec proxy-orch -- curl -s http://localhost:3098/api/clusters-info | python3 -m json.tool

Expected output:

[
  {
    "ClusterName": "pg-primary:5432",
    "ClusterAlias": "pg-primary:5432",
    "CountInstances": 3
  }
]

Check individual instance details:

# Via the API
multipass exec proxy-orch -- curl -s "http://localhost:3098/api/cluster/pg-primary:5432" | \
  python3 -c "
import json, sys
for inst in json.load(sys.stdin):
    key = inst['Key']
    role = 'PRIMARY' if not inst['ReadOnly'] else 'REPLICA'
    depth = inst['ReplicationDepth']
    print(f\"  {key['Hostname']}:{key['Port']} [{role}] depth={depth}\")
"

Expected output:

  pg-primary:5432 [PRIMARY] depth=0
  192.168.2.7:5432 [REPLICA] depth=1
  192.168.2.8:5432 [REPLICA] depth=1

Step 6: Check the Health Endpoint

Orchestrator exposes a health API useful for monitoring and Kubernetes liveness probes:

multipass exec proxy-orch -- curl -s http://localhost:3098/api/health | python3 -m json.tool

Key fields in the response:

{
  "Code": "OK",
  "Message": "Application node is healthy",
  "Details": {
    "Healthy": true,
    "Hostname": "proxy-orch",
    "IsActiveNode": true,
    "AvailableNodes": [
      {
        "Hostname": "proxy-orch",
        "AppVersion": "4.30.2",
        "DBBackend": "/usr/local/orchestrator/orchestrator.sqlite3"
      }
    ]
  }
}

Step 7: Access the Web UI

Orchestrator provides a visual topology on port 3098. From your Mac:

# Get the proxy-orch VM IP
multipass info proxy-orch | grep IPv4

Then open http://<proxy-orch-ip>:3098 in your browser. The web UI shows a draggable topology tree with the primary at the top and replicas below.

Useful API Endpoints

Step 8: Using orchestrator-client (CLI)

While the HTTP API works, orchestrator-client is faster for day-to-day operations and scripting. It wraps every API call into a clean command with formatted output. Here are the commands you'll use most often, with real output from our cluster.

View the topology tree:

export ORCHESTRATOR_API="http://localhost:3098/api"
orchestrator-client -c topology -i 192.168.2.6:5432

192.168.2.6:5432   [0s,ok,17.9,rw,>>]
+ 192.168.2.7:5432 [null,ok,17.9,ro,>>]
+ 192.168.2.8:5432 [null,ok,17.9,ro,>>]

The output reads as: host:port [replication_lag, check_status, pg_version, rw_or_ro, gtid_hint]. The + prefix means "replica of the line above."

List clusters and find the master:

orchestrator-client -c clusters

192.168.2.6:5432

orchestrator-client -c which-cluster-master -i 192.168.2.6:5432

192.168.2.6:5432

List replicas of a given instance:

orchestrator-client -c which-replicas -i 192.168.2.6:5432

192.168.2.7:5432
192.168.2.8:5432

Check for replication problems:

orchestrator-client -c replication-analysis

When the cluster is healthy, this returns nothing. During a failure, it shows:

192.168.2.6:5432 (cluster 192.168.2.6:5432): DeadPrimary

Control automatic vs manual recovery:

# Disable automatic promotion
orchestrator-client -c disable-global-recoveries

# Check current mode
orchestrator-client -c check-global-recoveries

disabled

# Trigger manual recovery
orchestrator-client -c recover -i 192.168.2.6:5432

# Re-enable automatic mode
orchestrator-client -c enable-global-recoveries

# Acknowledge past recoveries (unblock future ones)
orchestrator-client -c ack-all-recoveries --reason "tested failover"

Full command reference:

Step 9: Why Manual Failover Is the Default

Our configuration uses RecoverMasterClusterFilters: ["_do_not_match_"] — this means Orchestrator detects failures and alerts you, but does not automatically promote a replica. You trigger promotion manually when you're ready.

Why Not Automatic?

In MySQL, automatic failover is common because Orchestrator can rejoin the old primary as a replica using CHANGE REPLICATION SOURCE TO — a simple SQL command on a running server. If auto-failover mis-fires on a network glitch, the damage is recoverable.

PostgreSQL is different. We tested every Orchestrator rejoin method — relocate, move-below, repoint, move-gtid, set-read-only — both via CLI and HTTP API. All fail. PostgreSQL has no equivalent of CHANGE REPLICATION SOURCE TO. Once a replica is promoted, the old primary cannot be rejoined via Orchestrator. You must run a full pg_basebackup (which wipes the data directory and copies everything from scratch) or pg_rewind (which requires wal_log_hints=on to be configured in advance).

This means if automatic failover triggers on a network glitch (the primary is actually fine, just briefly unreachable):

1. Orchestrator promotes a replica → now you have two primaries (split-brain)
2. The old primary cannot be automatically demoted back to a replica
3. You must stop the old primary, wipe its data, and pg_basebackup from the new primary
4. On a large database, this takes minutes to hours

Manual mode avoids this entirely. Orchestrator still detects the failure instantly and fires alert hooks. You verify the primary is truly dead, then run one command to promote.

The Manual Failover Workflow

When a primary fails, Orchestrator logs the detection but does not act:

CheckAndRecover: Analysis: DeadPrimary, InstanceKey: 192.168.2.6:5432:
  NOT Recovering host (disabled globally)

The OnFailureDetectionProcesses hooks still fire — use these for Slack/PagerDuty alerts. You investigate, confirm the primary is dead, then promote:

export ORCHESTRATOR_API="http://localhost:3098/api"

# Check what Orchestrator sees
orchestrator-client -c replication-analysis

192.168.2.6:5432 (cluster 192.168.2.6:5432): DeadPrimary

# Verify the primary is truly unreachable (not just a network blip)
PGPASSWORD=monitor_pass_2026 psql -h 192.168.2.6 -U monitor -d postgres -c "SELECT 1;" 2>&1

If connection fails, the primary is genuinely down. Promote:

orchestrator-client -c recover -i 192.168.2.6:5432

192.168.2.7:5432

Orchestrator selects the most caught-up replica and calls pg_promote(). ProxySQL detects the new primary within seconds and reroutes traffic.

After recovery, acknowledge to unblock future failovers:

orchestrator-client -c ack-all-recoveries --reason "verified dead primary, promoted replica"

Enabling Automatic Mode (If You Choose To)

If your network is stable and you accept the risk, you can enable automatic recovery. This requires both layers to allow it:

1. Config filter — change RecoverMasterClusterFilters so your cluster name matches
2. Runtime toggle — must be enabled (it is by default)

With our default config (["_do_not_match_"]), the runtime toggle is already enabled but no cluster matches the filter — so auto-recovery is blocked. To enable auto-recovery, change the config filter:

Change RecoverMasterClusterFilters in /usr/local/orchestrator/orchestrator.conf.json and restart Orchestrator:

"RecoverMasterClusterFilters": [".*"]

Or scope to specific clusters only:

"RecoverMasterClusterFilters": ["production-critical-.*"]

You can also use the runtime toggle as a temporary kill switch (no restart needed):

# Temporarily block all auto-recovery (e.g. during maintenance)
orchestrator-client -c disable-global-recoveries

# Re-enable
orchestrator-client -c enable-global-recoveries

# Check current state
orchestrator-client -c check-global-recoveries

Step 10: Understanding Failover Hooks

Orchestrator runs configurable processes at each failover stage. In our config, we log to /tmp/orchestrator-recovery.log. In production, you'd use these hooks to:

1. Pre-failover: Drain the old primary in ProxySQL (OFFLINE_SOFT)
2. Post-failover: Update ProxySQL's pgsql_servers to reflect the new topology
3. Notification: Alert via Slack, PagerDuty, etc.

Example production hook for ProxySQL integration:

#!/bin/bash
# /usr/local/bin/proxysql-failover-hook.sh
# Called by Orchestrator's PostMasterFailoverProcesses

NEW_PRIMARY="$1"
OLD_PRIMARY="$2"

PGPASSWORD=admin psql -h 127.0.0.1 -p 6132 -U admin -d admin << EOF
-- Move old primary to reader hostgroup
UPDATE pgsql_servers SET hostgroup_id = 20 WHERE hostname = '${OLD_PRIMARY}';
-- Move new primary to writer hostgroup
UPDATE pgsql_servers SET hostgroup_id = 10 WHERE hostname = '${NEW_PRIMARY}';
LOAD PGSQL SERVERS TO RUNTIME;
SAVE PGSQL SERVERS TO DISK;
EOF

Troubleshooting

Pre-Checks Before Moving to Part 4

Part 4 will kill the primary and expect automated recovery. Every check below must pass or the failover will fail silently or produce confusing errors.

echo "=== Orchestrator Pre-Check Suite ==="

echo "1. Orchestrator process running:"
multipass exec proxy-orch -- pgrep -c orchestrator

echo "2. Health endpoint responds OK:"
multipass exec proxy-orch -- curl -s http://localhost:3098/api/health | python3 -c \
  "import json,sys; d=json.load(sys.stdin); print(f'  Healthy: {d[\"Details\"][\"Healthy\"]}, Active: {d[\"Details\"][\"IsActiveNode\"]}')"

echo "3. Single cluster with 3 members:"
multipass exec proxy-orch -- curl -s http://localhost:3098/api/clusters-info | python3 -c \
  "import json,sys; [print(f'  {c[\"ClusterName\"]}: {c[\"CountInstances\"]} members, AutoRecovery={c[\"HasAutomatedMasterRecovery\"]}') for c in json.load(sys.stdin)]"

echo "4. Topology correct (1 PRIMARY + 2 REPLICA):"
multipass exec proxy-orch -- curl -s "http://localhost:3098/api/cluster/$(multipass exec proxy-orch -- curl -s http://localhost:3098/api/clusters-info | python3 -c 'import json,sys;print(json.load(sys.stdin)[0][\"ClusterName\"])')" | python3 -c \
  "import json,sys; [print(f'  {i[\"Key\"][\"Hostname\"]}:{i[\"Key\"][\"Port\"]} [{\"PRIMARY\" if not i[\"ReadOnly\"] else \"REPLICA\"}]') for i in json.load(sys.stdin)]"

echo "5. HasAutomatedMasterRecovery = true:"
multipass exec proxy-orch -- curl -s http://localhost:3098/api/clusters-info | python3 -c \
  "import json,sys; c=json.load(sys.stdin)[0]; print(f'  AutoRecovery: {c[\"HasAutomatedMasterRecovery\"]}')"

echo "6. No stale recovery blocks:"
multipass exec proxy-orch -- curl -s http://localhost:3098/api/audit-recovery | python3 -c \
  "import json,sys; d=json.load(sys.stdin); print(f'  Pending recoveries: {len(d)}')"

echo "7. Orchestrator user can call pg_promote():"
multipass exec pg-primary -- sudo -u postgres psql -tAc \
  "SELECT usesuper FROM pg_user WHERE usename = 'orchestrator';"

echo "8. ProxySQL still routing correctly:"
multipass exec proxy-orch -- PGPASSWORD=admin psql -h 127.0.0.1 -p 6132 -U admin -d admin \
  -c "SELECT hostgroup_id, hostname, status FROM runtime_pgsql_servers ORDER BY hostgroup_id;"

echo "=== All Orchestrator pre-checks complete ==="

What's Next

Orchestrator is running, discovering the topology, and ready to handle failures. In Part 4, we put everything together and run real failover scenarios:

• Kill the primary VM and watch automatic recovery
• Planned switchover using Orchestrator's graceful takeover API
• Rejoin a failed primary as a replica
• End-to-end verification through ProxySQL after each failover
• Production hardening checklist
